Excavator
E6800H
Operating weight,kg (lbs)
79000kg
Bucket capacity (m³)
5.2m³
Bucket capacity range
4.8~5.6
Talk to sales directly —
Anthony 086 223 7039
or Ronald 087 915 3459
.
Demos arranged nationwide.
- Features
- Technical Parameter
Features
- Super Strong Power, Energy-saving and Consumption Reduction
- 563kW high-power engine with sufficient power reserve; equipped with a power divider, featuring low speed, large torque, low fuel consumption and high efficiency. No after-treatment system, no need to add urea, reducing the use cost.
- Full Electronic Control Hydraulic System, Fuel-saving and Efficient
- The main valve integrates proportional solenoid valves to achieve full electrical control. Wire harness connection replaces pilot lines, making the oil circuit simpler with small pressure loss.
- Dual independent electronic control main pumps and large-diameter main valves realize the optimal matching of power and hydraulics, fully exerting the operation performance and improving the operation efficiency.
- Large-torque swing motor for smooth swinging.
- Intelligent Temperature Control, More Durable Operation Capability
- Super large radiator with dual independent temperature control, lower power consumption and more energy-saving, maintaining the optimal working oil temperature.
- Enlarged fan with low-speed control, low noise and high efficiency, meeting the high-load mine operation.
- The cooling fan can reverse, achieving both heat dissipation and dust removal.
Technical Parameter
| Operating Weight (kg) | 79000kg |
| Bucket capacity (m³) | 5.2m³ |
| Bucket capacity range | 4.8~5.6 |
| Average ground pressure | 115.4mm |
| Slewing speed | 7r/min |
| Traveling speed (low/high) | 3.0/4.9km/h |
| Maximum digging force | 405.5kN |
| Altitude | 3500m |
| Wading depth | 1095mm |
| Engine model/Drive Motor Model | 6WG1XDEAA-01 |
| Engine power | 377KW |
| Maximum flow rate | 510×2L/min |
| Fuel specifications and filling amount | 1100L |
| Overall length | 12915mm |
| Overall width | 4490mm |
| Overall height | 5100mm |
| Boom length | 7000mm |
| Wheel track | 2810/3410 |
| Arm length | 2800mm |
| wheelbase | 4750mm |
| Crawler wheelbase/Wheelbase | 4750mm |
| Maximum digging radius | 12000mm |
| Maximum digging depth | 7315mm |
| Maximum discharge height | 7060mm |
| Overall length during transfer | 12915mm |
| Shovel width (with band edge) | 2235mm |
| Maximum digging depth under length of bottom surface of 2.5m | 7160mm |
| Maximum digging height | 11085mm |
| Contour dimension of complete machine (transfer position) | 12915×4490×5100mm |
| Overall width of upper assembly | 3470 |
| Overall width of chassis | 3722/4322mm |
| Overall height to cab top | 3725mm |
| Rear slewing radius | 4210mm |
| Overall height to hood top | 3430mm |
| Ground clearance of upper assembly | 1580mm |
| Overall length of crawler | 5970mm |
| Wheel track of crawler/Wheel track | 2810/3410mm |
| Track shoe width | 650mm |
| Minimum ground clearance | 890mm |
| Overall height of working mechanism during transfer | 5100mm |
| Maximum digging radius of reference ground | 11720mm |
| Maximum vertical digging depth | 4420mm |
| Minimum front turning radius | 5420mm |
